GX and GX2 Series Ventilator Cartridge Identification Sheet
The following information is needed in order to identify the correct GX Extractor for your
Ventilator:
1. Measure and fill in the Height of the Cartridge opening of the exhaust hood.
2. Measure and fill in the Depth of the Cartrdge opening of the exhaust hood.
3. Measure and fill in the Length of the Cartridge opening of the exhaust hood.
4. Does the Ventilator have Extractor Hanging Clip Style “A” _____ or Style “B” ______
5. The Ventilator Model # prefix is GX _____ GX2 _____ (See Ventilator Nameplate)
6. Approximate year the hood was built. __________________
For GX Series For GX2 Series Ventilator
Dimensions Cartridge
Series # Dimensions Cartridge
Series #
Depth = 7” and Height = 10” GX-400 Height = 12” GX2-400
Depth = 5” and Height = 7-1/2” GX-250 Height = 11” GX2-250
Depth = 3” and Height = 5-1/4” GX-150
Name __________________________________
Company Name __________________________
Phone # ________________________________
Email __________________________________
This Dimension or the dimension
from remaining Cartridges to the
end is _________”
Style “B”
Figure 1
Side Section View
Style “A”
Height _____”
Depth _____”
Figure 2
Front View
