Controller − The ANSUL® RED controller provides the inputs They are available in five preset temperatures which meet NFPA
and outputs (I/Os) used to protect up to two hazard areas standards and are UL Listed and FM Approved.
and activate the release outputs as required. It also provides
connections for two additional optional relay modules. All Temperature
circuits are monitored for open or short conditions. Features Rating
include: 225 °F (107 °C)
n Six configurable inputs* 325 °F (162 °C)
– 3.3 VDC, 0.5 mA – 2.2 mA 450 °F (232 °C)
– Pull station is current limited to 1.5 mA in alarm. 600 °F (315 °C)
n Two releasing circuits* (one PAD each) 725 °F (385 °C)
– Polarity reversal circuit Relay Board − The relays are intended for use with electric gas
valves, alarms, contactors, lights, contractor supplied electric
– 1 A, 10 msec pulse power shut-off devices and other electrical devices that are
designed to shut off or turn on when the system is actuated.
n Two cartridge monitoring circuits*
The relay board is used to add three high-power relays to the
– Current limited to 1.5 mA – 2.2 mA depending on number controller. Up to two relay boards may be added to a controller.
of missing cartridges. Each relay contains three terminals which can be used to wire
n Provides 12 VDC Power*, 100 mA max, for a display module the circuit for normally open (NO) or normally closed (NC).
n AC primary power (120/240 VAC, 50/60 Hz, 270 mA) UL Rating - 277 VAC, 16A Resistive
n Rechargeable backup battery VDE Rating - 250 VAC, 16A Resistive
n Two relays to provide Alarm and Trouble status to a Building
Fire Alarm Control Panel Regulated PAD Release − The regulated PAD release assembly
contains the regulated release, expellant gas hose for agent
– 0.5 A, 120 VAC or 2 A, 30 VDC tank hookup, and enclosure knockouts to facilitate installing
actuation piping, expellant piping, release wiring, and additional
– Relay 1 is configurable using a jumper located on the equipment. This regulated release assembly is used in single,
board. Default is NC. double, and multiple-tank systems and must be mounted to a
– Relay 2 is only NO contact rigid surface. The release can be used to interconnect both the
actuation and expellant gas lines as required per system design.
n Up to two (2) relay modules (expandable) The regulator is designed to allow a constant flow of gas into
– 3 relays per module the tank at 110 psi (7.6 bar) for R-102 or 150 psi (10.3 bar) for
PIRANHA when the system is actuated. The agent tank must be
n Removable board for ease of controller box and conduit ordered separately.
installation.
* The wiring for these circuits are monitored for ground faults. The Electric Remote Manual Pull Station − The electric remote
sensitivity is 10 K ohms to ground. manual pull station is made out of a molded red composite
material. The red color makes the pull station more readily
identifiable as the manual means for fire suppression system
operation.

Battery − A 12 V 5.0 Ah sealed lead acid (SLA) battery is used to
provide backup power for the system in the event there is an AC
power failure. The battery provides 24 hours of backup power.

High Temperature Connector Assembly − The high temperature
connector assembly is used to connect two linear detection
wires of different temperature ratings within a hood. This is
useful when different appliances require different linear wire
010885 temperature ratings within a hazard area.
Linear Detector Wire − The linear detection wire provides fire
detection in the protected area. Linear detection wire is available Approvals
in the following four color-coded temperature offerings:
n UL and ULC Listed (UL300)
Temperature
Rating Color of Wire n Meets requirements of NFPA 96 (Standard for the Installation
of Equipment for the Removal of Smoke and Grease-Laden
155 °F (68 °C) Gray Vapors from Commercial Cooking Equipment)
280 °F (137 °C) Blue n Meets requirements of NFPA 17A (Standard on Wet Chemical
356 °F (180 °C) Red Extinguishing Systems)
500 °F (260 °C) Orange

Note: The converted values in this document are provided for dimensional
Thermal Detectors − Rate compensating temperature thermal reference only and do not reflect an actual measurement.
detectors are normally open (NO) mechanical contact closure ANSUL® and the product names listed in this material are marks and/or
switches designed to operate at a factory preset temperature. registered marks. Unauthorized use is strictly prohibited.
