MODEL “GPC-7000-SPC-SO-R”

COMBINED WASH CONTROL
and REMOTE SPRAY ODOR CABINET for
POLLUTION CONTROL CLEAN-IN-PLACE VENTILATORS
GENERAL SPECIFICATIONS AND DESCRIPTION
Furnish Combined Wash Control Cabinet and Remote Spray Odor Cabinet
Model “GPC-7000-SPC-SO-R _______” to house electrical and plumbing
components for operation of the Eliminator Pollution Control Clean-In-
Place Ventilator(s) and Duct Sump(s), if specified.
CONTROLS: The Remote Wash Control Cabinet shall include a built-in
Gaylord Command Center to control all functions of the exhaust and supply
fans, the Extractor and Plenum Wash cycles, UVi Lamps, Pollution Control
Ventilator, Spray Odor Control and Ducts Sumps, if specified. The control
shall be a programmable logic controller (PLC) based unit with a touch
screen display interface. The touch screen shall include the “START FAN” and
“STOP FAN” buttons and a “MENU” button to easily access all programming
functions. The display shall show all current operating modes such as “FAN
ON”, “FAN OFF”, “EXTRACTOR WASH ON”, etc. Remote Cabinet
Programming features shall include:
1. Setting the duration and frequency of each Extractor (Face and APPLICATION
Internal Passages of Extractors) and Plenum Wash Cycle for For use with Eliminator Pollution Control Clean-in-Place Ventilators with
each Ventilator section independently, based upon type and or without UVi and Gaylord Duct Sumps (GDS).
duration of cooking. NUMBER REQUIRED
2. Setting the duration of each ESP Cell Wash Cycle for each One control cabinet can be used for up to five (5) Ventilator sections. Any
Ventilator section independently, based upon type and duration number of exhaust fans and supply fans can be connected to the Wash
of cooking. Control Cabinet, if simultaneous operation is desired. If there are two or more
3. Optional setting to automatically “START FAN” and “STOP FAN” groups of ventilators, each with their own exhaust fan, and independent
at specific times for each day of operation. operation of the fans is desired, consult factory for options.
4. Optional lockout of all operations for days not operating.
FEATURES
The Gaylord Command Center shall include volt-free contacts for optional; • Touch Screen Operation, Programming and Display
1) interfacing the exhaust and supply fans with a building management • Individual Wash Settings for each Ventilator Section, Extractor
system or other control circuits to monitor the system and/or to allow (Face and Internal Passages of Extractors) and Plenum, based upon
remote START and STOP OF exhaust fans, and 2) for interfacing with a fire Cooking Type
extinguishing system to send a signal to the building fire alarm system and/ • Autostart to Meet International Mechanical Code (IMC)
or notify the building management system of a fire extinguishing system • Remote Fan Start/Stop from Building Management System
discharge. The Gaylord Command Center shall also monitor and display • Monitor Fire Extinguishing System Discharge
status of; 1) “UVi System On”, “UVi Lamp Failure”, “UVi Standby”, 2) Total • Built-in Time Clock
Hours of UVi Lamp Operation, 3) “ESP Fault “, “ESP OK”, 4) Low Detergent • Built-in Back Flow Preventer
notification, if option is specified. In addition, the control shall monitor
the “Autostart” sensors mounted in the Ventilator(s), if equipped, and
automatically start the exhaust and supply fan(s) when cooking occurs OPTIONAL EQUIPMENT:
when the fans are off and if the temperature is above the sensor’s set point. Backflow Field Connection Detergent Monitor - The Wash Control
The Gaylord Command Center shall be equipped with a battery back-up Cabinet shall include a detergent flow switch to monitor detergent levels and
to hold the clock and memory for programming functions. display a message on the Gaylord Command Center to notify of low detergent.

PLUMBING: Plumbing components shall consist of a line strainer, shut-off Low Detergent Monitor - The Wash Control Cabinet shall include a
valve, reduced pressure principle device backflow preventer, pressure/ detergent flow switch to monitor detergent levels and display a message
temperature gauge, detergent pump, a detergent container, spray odor on the Gaylord Command Center to notify of low detergent.
catalyst pump, and a spray odor catalyst drum. Required water solenoid
valves are provided by Gaylord and are mounted at each Ventilator section. Light Switch - The Wash Control Cabinet shall include a built-in light switch
for interconnection to the ventilator lighting circuit.
INTERCONNECTIONS: All plumbing and electrical interconnections
between the Wash Control Cabinet, the building services and the Security Access- The Wash Control Cabinet door shall be equipped with
Ventilators shall be the responsibility of the applicable trades. Backflow keyed latch to prevent unauthorized access to the controls.
certification by field plumber.
Trim Ring- The Wash Control Cabinet shall include a full perimeter one
CONSTRUCTION: The Wash Control Cabinet shall be of all stainless steel piece adjustable trim ring.
construction, not less than 18 gauge, type 300 series. All exposed surfaces
shall be a number 4 finish. The use of aluminized steel or galvanized steel ACCEPTANCE & APPROVALS: The Wash Control Cabinet and Remote Cabinet
is not acceptable. The Wash Control Cabinet shall have welded corners shall be ETL Listed and comply with all requirements of the International
and hinged doors to the plumbing and electrical compartments. Electrical Plumbing Code (IPC), Uniform Plumbing Code (UPC), and the National
compartment shall be watertight to protect against direct hose spray. Electrical Code (NEC).
