ELXC SERIES

ITEM NO. _______________
MODEL “ELXC-SPC-SO”

HIGH EFFICIENCY EXTRACTOR VENTILATOR
WITH CLEAN-IN-PLACE TECHNOLOGY,
ULTRAVIOLET IRRADIATION, ODOR CONTROL
& ELECTROSTATIC PRECIPITATOR FOR SMOKE CONTROL

GENERAL SPECIFICATIONS AND DESCRIPTION

Furnish Gaylord Ventilator Eliminator Model “ELXC-SPC-SO_________”
as shown on plans and in accordance with the following specifications:
HIGH EFFICIENCY EXTRACTION: Each ventilator shall contain “XGS”
High Efficiency Extractors utilizing the “capture and drain” principle.
Extractor efficiencies shall be determined using ASTM F2519-2005 testing
procedures. The “capture and drain” principle shall prevent water from
entering the plenum and duct areas during “FAN ON” wash cycles, thus
providing 24/7 operators the full effect of Clean-In-Place technology. Each
ventilator shall contain secondary filters to enhance performance and
optimize efficiency positioned between the XGS High Efficiency Filters
and UV Lamps.

HOOD CONTROLS: Each ventilator shall be IMC compliant and
incorporates canopy mounted RTD’s positioned strategically across the
length of the hood. APPLICATION
Wall mounted canopy for use over all types of equipment; ovens, broilers,
CAPTURE AND CONTAINMENT: Each ventilator shall achieve capture griddles, fryers, ranges, steam equipment, etc.
and containment using the lowest possible airflow rates and may include
an integrated capture wall. DESIGN FEATURES
CLEAN-IN-PLACE WASH TECHNOLOGY: Each ventilator shall include • Demand Control Autostart
two full length stainless steel wash manifolds with brass nozzles; one to • Clean-In-Place Technology
wash the inlet face and internal passages of the extractors during “FAN • Ultraviolet System
ON” mode and one to wash the plenum chamber during the “FAN OFF”
mode as programmed by the Gaylord Command Center. Each wash • Smoke and Odor Control
manifold on each ventilator section shall operate independently so each
wash cycle may be programmed at different frequencies and different OPTIONAL EQUIPMENT
durations to reduce water and detergent usage and optimize cleaning 1. Cold Water Mist
efficacy according to load and demand. Each ventilator section shall drain
to sloping gutters with 2” outlets. 2. Decorative Facings and Trim
3. AirVantage DCKV
ULTRAVIOLET SYSTEM: The ventilator shall include ultraviolet lamps 4. Smoke Filter & Safety Media Bed Odor Control Module
mounted in modules located in the plenum section(s). The UV module 5. Fire Extinguishing Systems
shall be on a slide track for easy removal. Access to the UV modules shall
be through keyed and hinged access doors. Two redundant pressure 6. Utility Distribution Systems
switches shall be provided to monitor the airflow and prevent operation
of the UV lamps if the access doors are open, or if any “XGS” Extractor is guidelines. Each cell shall have 12 tungsten wires run perpendicular to
removed, or if the airflow is inadequate. Mounted on the canopy roof of the exhaust air flow which will ionize the air stream. Spike type systems
each ventilator section shall be status lights to monitor “UVi System On”, shall not be accepted. The cell shall be positioned on slide tracks so it may
“UVi Lamp Failure”, “UVi System Stand By”, and cell operational status. The be easily removed through a cell access door. For ease of handling, each
Gaylord Command Center shall display text that duplicates the ventilator individual cell shall weigh less than 45lbs. An electrical panel mounted in
mounted status lights. UV system shall incorporate a high temperature the unit shall contain the high voltage power pack assembly and safety
shut down set to trigger upon detection of excessive temperatures. disconnect switch for safe operation. The safety disconnect switch shall
interface with the electrical panel access door such that when opened
COLD WATER MIST: An optional cold water mist manifold may be installed it will shut off service to the power pack(s) and ground them to drain
at the hood inlet for heavy or extra heavy-duty applications. the residual electrical charge from both the power pack(s) and ESP cell.
The high voltage power pack(s) shall be self-limiting type and shall be
ODOR NEUTRALIZER: The Ventilator shall contain spray nozzles supplied self-contained. The unit shall contain wash manifold(s) on the top of the
with water from the building cold water supply system and supplied with cell and the inlet side of the cell with fixed spray nozzles to wash the ESP
an odor catalyst that works in conjunction with the UV Lamps. The volume cell daily with detergent-injected hot water. Required wash pressure is
of odor catalyst will vary based on the system recognizing and adapting
to the cooking activity and environment.
SMOKE CONTROL SECTION: The smoke control section shall contain
one electrostatic precipitator (ESP) cell to remove smoke particles from
the air stream to industry standards or to a level of 95% efficiency in
accordance with ASHRAE std 52.2 resulting in no higher than 20% opacity
when operated in accordance with the operation and maintenance
